Excellent quality Ssd1325 Oled - 2.4inch transparent lcd screen use for mobile phone TP241MC01G – New Display

Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
OLED
Model Number:
TP241MC01G
Type:
TFT
size:
2.4″
resolution:
240*320
Interface:
8bit Parallel Data with MPU (8080-series MPU)

Packaging & Delivery
Packaging Details
original packing
Port
HK

  2.4inch transparent lcd screen use for mobile phone TP241MC01G

LCD size

2.4 ”

Resolution

240(W) x RGB x 320(H)

Outline Dimension

42.92(W) x 69.46(H) x 1.4(T)

Panel Outline

42.92(W) x 59.46(H) x 1.4(T)

Viewing Area

37.72(W) x 49.96(H)

Active Area

36.72(W) x 48.96(H)

  Pixel Pitch

0.153(W) x 0.153(H)

1. Features
Display Format : 240(W) x RGB x 320(H) dots
Display Color : 16M Color(24bit per pixel) / 65K Color(16bit per pixel)
Driver Element : Passive Matrix Transparent OLED
Interface : 8bit Parallel Data with MPU (8080-series MPU)
Multiplexing Ratio : 1/320 Duty
Control (Drive) IC : DA8620 (Manufacturer : Dialog Semiconductors)
Polarizer : Without Polarizer

  More information from Shenzhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO/ /Innolux/ TianMa five brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3. Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;
4.long-term partner:
* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;
5. Super After-Sale service:
Shenzhen New display will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;
6.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site : https://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
